Minelab GPZ 7000
Product Details

The Minelab GPZ 7000

Ultimate depth Ultimate Control


When you want the very best in gold detection, the Minelab GPZ 7000 is the answer.

With extreme depth and maximum sensitivity on all gold, the innovative GPZ 7000 gold detector takes you to the next level of gold detection


ZVT

ZVT (Zero Voltage Transmission) creates ultra‑constant high-power opposite polarity magnetic fields, increasing gold sensitivity. This innovative technology detects gold nuggets at extreme depths.

ZVT technology goes to the NEXT LEVEL for all serious gold prospectors, providing substantially improved depth. No longer will you be limited to using either sine wave continuous VLF transmission detectors, that struggle in mineralized ground, or square wave PI transmission detectors, that can be insensitive to varying gold sizes and compositions.

Minelab's new flagship gold detector, the GPZ 7000 is equipped with exclusive Zero Voltage Transmission (ZVT) technology, developed by Bruce Candy, and state-of-the-art features, the GPZ 7000 offers the deepest ground penetration and represents the most significant advancement in gold detecting technologies in years. This revolutionary gold detector will discover the deepest gold in mineralized ground and has the highest sensitivity available to detect even the smallest traces of gold.

GPZ 7000 TECH SPECS

Application
Gold Prospecting (Waterproof coil to 1m/3ft)
Technology
ZVT
Frequency/Transmission
Zero Voltage Transmission (ZVT)
Coil (standard)
14" x 13" Super‑D Configuration with skidplate (waterproof to 1 m/3 ft)
Audio Output
6.3 mm (¼") non waterproof socket, Wi‑Stream wireless signal transmission
Headphones Supplied
KOSS UR 30 100 ohm with 6.3 mm plug (¼-inch) (non waterproof)
Visual Display
Full colour LCD (320 x 240 pixels)
Backlight
Yes
Product ID
252529
USB Connectivity
USB interface for XChange 2 PC software
Memory
Yes
Depth Indication
-
Detect Modes
Gold Mode (High Yield, General, Extra Deep) Ground Type (Normal, Difficult, Severe)
Discrimination
All Metal
Timings
-
Audio tone
1-100
Audio Type
-
Ground Balance
Auto and Manual (Quick‑Trak trigger button)
Ground Balance Type
Auto and Manual (Quick‑Trak trigger button)
Trash Density
-
Pinpoint
-
Sensitivity Adjust
Level (1-20)
Tune / Noise Cancel
Auto and Manual (256 channels)
Threshold
Level (1-50) Pitch (1-100)
Target Volume Adjust
Range (1-20) Limit (1-20)
Battery
Li-Ion Rechargeable Pack (7.2V DC, 72Wh)
Low battery alert
Yes
Length
Collapsed: 1170 mm (46.1”) Laid flat, packed position: 1304 mm (51.3”) Extended: 1526 mm (60.1”) Laid flat, packed position: 1651 mm (65.0”)
Weight
3.32 kg (7.32 lb) (Including GPZ 14 coil, skidplate and 72Wh battery)
Warranty
3 years control box & coil
